Food Grade Isolation PPSU Solenoid Valve for Coffee Machine 12V 24V 110V 220V

Brand Name : BRANDO

Model Number : 7.13CAFXXXBW9

Certification : CE, ISO

Place of Origin : Ningbo, China

MOQ : 100pcs

Price : Negotiation

Payment Terms : T/T, PayPal, Western Union

Supply Ability : 50000 pcs per month

Delivery Time : 4 to 7 working days

Packaging Details : Box, Carton, Pallet

Orifice Size : 2.5mm, 3.0mm, 4.0mm, 4.5mm, 4.8mm

Port Size : 9.0mm OD

Function : 2 Way Normally Closed

Operation : Isolation

Body Material : PPSU

Working Pressure Range : 0 to 6 bar

Voltage : 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Application : Coffee Maker, Beverage Machine, etc

Contact Now

Food Grade Isolation PPSU Solenoid Valve for Coffee Machine 12V 24V 110V 220V


Product Features:

1. Working Medium: Corrosive Fluids, Chemicals, Acid, Alkali, Steam, Coffee, Beverage, etc

2. Medium Temperature: FKM (-30 to +150℃), FFKM (-40 to +180℃)

3. Working Pressure: 0 to 6 bar (pls see below datasheet)

4. Body Material: PPSU

5. Seal Material: FKM, FFKM

6. Port Size: 9mm barb

7. Orifice Size: 2.5mm, 3mm, 4mm, 4.5mm, 4.8mm

8. Function: 2 Way Normally Closed

9. Operation: Direct Acting

10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data:

Food Grade Isolation PPSU Solenoid Valve for Coffee Machine 12V 24V 110V 220V

Model No. Port size Orifice Size (mm) Mini Pressure Max Pressure Seal Material Body Material
7.13AAF028BQF Φ6mm ID 2.8 0.0 bar 0 bar 5 bar EPDM PPSU
Model No. Port size Orifice Size (mm) Mini Pressure Max Pressure Seal Material Body Material
Port 1 to Port 2 Port 2 to Port 1
7.13CAF025BXX Male, Female 2.5 0.0 bar 6 bar 2.8 bar FKM
FFKM		 PPSU
7.13CAF030BXX 3.0 0.0 bar 5.5 bar 2 bar
7.13CAF040BXX 4.0 0.0 bar 3.5 bar 1.3 bar
7.13CAF045BXX 4.5 0.0 bar 3 bar 1 bar
7.13CAF048BXX 4.8 0.0 bar 2.8 bar 0.9 bar

Production Show:

Food Grade Isolation PPSU Solenoid Valve for Coffee Machine 12V 24V 110V 220V

Production Video:
